Model: KVF-12075-TDH / KVF-24075-TDH

Output:

• DC Voltage: 12V / 24V
• Voltage Tolerance: ±0.5V
• Rated Current: 6.25A / 3.125A
• Rated Power: 75W

Input:

• Voltage Range: 200-240VAC
• Frequency Range: 47~63Hz
• Power Factor: PF ≧ 0.98 (200VAC / 230VAC / 240VAC, Full load)
• Full Load Efficiency (Typ.): 85%
• AC Current (Max.): 0.55A
• Leakage Current: <0.50mA

Protection:

• Short Circuit: Output voltage shuts down, re-power on to recover after fault condition is removed.
• Overloading: ≦120% in hiccup mode, automatically recovers after fault condition is removed.
• Over Current: ≦ 1.2 * Iout
• Over Temperature: Shuts down at 100°C ± 10°C, re-power on to recover.

Environment:

• Working Temperature: -40°C to +70°C
• Working Humidity: 20-90%RH, non-condensing
• Storage Temperature & Humidity: -40°C to +80°C, 10-95%RH
• Temperature Coefficient: ±0.03%/°C (0-50°C)
• Vibration: 10-500Hz, 2G, 10 min./1 cycle, 72 min. along X, Y, Z axes

Safety & EMC:

• Safety Standards: EN61347-1, EN61347-2-13
• Withstand Voltage: I/P-O/P: 3.75KVAC
• Isolation Resistance: I/P-O/P: 100MΩ/500VDC/25°C/70%RH
• EMC Emission: EN55015, EN61000-3-2,3 (≧60% loading)

Others:

• Net Weight: 0.45 kg
• Size: 180 x 60 x35mm (LWH)
• Packing: 355x 215 x 150mm outer carton, 20 PCS/CTN

Notes:

1. All parameters not specifically mentioned are measured at 230VAC input, rated load, and 25°C ambient temperature.
2. Tolerances include setup tolerance, line regulation, and load regulation.
3. The power supply is intended to be used as a component with other equipment. EMC performance may be affected by the complete installation, requiring final equipment manufacturers to re-qualify EMC Directive compliance.
4. Loading range: 10% to 100%.
