Model Specifications:

• Models:
• Certifications:

Output Characteristics:

• DC Voltage: 12V, 24V, 36V, 48V (Adjustable by NFC)
• Voltage Tolerance: ±0.5V
• Voltage Regulation: 0.5%
• Rated Current: 16.67A (12V), 8.33A (24V), 5.56A (36V), 4.17A (48V)
• Rated Power: 200W
• Load Regulation: 2% (for higher voltages), 1% (for lower voltages)

Input Specifications:

• Voltage Range: 100-277VAC
• Frequency Range: 47 - 63Hz
• Power Factor (Typ.): PF≥0.98@120VAC, PF≥0.98@230VAC, PF≥0.97@277VAC
• THD (Typ. @ full load): ≤15%
• Efficiency (Typ. @ full load): 90%-93.5%, varying by voltage and region
• AC Current (Max.): 2.3A
• Inrush Current (Typ.): Varies with input voltage
• Leakage Current: <0.5mA

Protection Features:

• Short Circuit: Hiccup mode, automatic recovery
• Overload: ≤120%, hiccup mode, automatic recovery
• Over Temperature: Shell surface temp ≤ 100°C±10°C, automatic recovery after cooling

Environmental Conditions:

• Operating Temperature: -40~+60°C
• Operating Humidity: 20 - 95% RH non-condensing
• Storage Temperature and Humidity: -40 - +80°C, 10 - 95% RH
• Temperature Coefficient: ±0.03%/°C (0 - 50°C)
• Vibration: 10~500Hz, 5G for 72min. along X, Y, Z axes

Safety & EMC:

• Safety Standards: EN61347-1, EN61347-2-13 (EU), UL8750, CAN/CSA-C22.2 No. 250.13 (US)
• Withstand Voltage: Specified for EU and US standards
• Isolation Resistance: I/P-O/P: 100MΩ / 500VDC

Additional Information:

• Net Weight: 1.05Kg
• Dimensions: 279 x 78 x 25.1mm (L x W x H)
• Packing: 330 x 300 x 210mm, 20pcs/CTN
• Notes: All parameters measured at rated load and 25°C unless specified. Tolerance includes setup and load regulation.
