KV-DP2 DALI-2/PUSH 2-in-1 Dimmable LED Driver 30W

SKU: KV-24030-DP2

KV-DP2 DALI-2/PUSH 2-in-1 Dimmable LED Driver 30W

SKU: KV-24030-DP2
/
  • Customizable
  • Worldwide shipping
  • Secure payments

Features:

  • Output: Constant Voltage
  • Voltage Range: 100-277VAC (US) & 200-240VAC (EU)
  • PFC Design: Built-in active PFC function
  • Efficiency: Up to 84%
  • Protections: Short circuit, overload, over temperature
  • Heat Dissipation: Cooling by free air convection
  • Waterproof Performance: IP20 rated for indoor use; full plastic housing suitable for dry and damp locations
  • Dimming Function: DALI2 & PUSH digital dimming; flicker-free
  • Dimming Range: 0-100% with a depth of 0.1%
  • NFC Function: Fine-tune output voltage, write and read addresses
  • Application: Suitable for LED lighting and moving sign applications
  • Warranty: 5 years
Tax included. Shipping calculated at checkout.
Enquiry now
KV-DP2 DALI-2/PUSH 2-in-1 Dimmable LED Driver 30W

Product Specification

Specification Overview: DALI-2/PUSH 2-in-1 Dimmable LED Driver 30W

Models:

  • KV-12030-DP2
  • KV-24030-DP2
  • KV-36030-DP2
  • KV-48030-DP2

Certifications:

  • UL, cUL, Class 2, Class P, FCC, ENEC, CE, SELV, ROHS, Reach, DALI2

Output Specifications:

  • DC Voltage Options: 12V, 24V, 36V, 48V (Adjustable via NFC within ranges specified)
  • Voltage Tolerance: ±0.3V (12V, 24V), ±0.5V (36V, 48V)
  • Voltage Regulation: 0.5%
  • Rated Current: 2.5A (12V), 1.25A (24V), 0.83A (36V), 0.63A (48V)
  • Rated Power: 30W
  • Load Regulation: 2% (12V, 24V), 1% (36V, 48V)

Input Specifications:

  • Voltage Range: 100-277VAC (US) & 200-240VAC (EU)
  • Frequency Range: 47 - 63Hz
  • Power Factor (@ full load): ≥0.98 @ 120VAC, ≥0.95 @ 230VAC, ≥0.90 @ 277VAC
  • THD (Typ. @ full load): ≤15%
  • Efficiency (@ full load): 82% @ 120VAC 60Hz, 84% @ 230VAC 50Hz, 84% @ 277VAC 60Hz
  • AC Current (Max.): 0.42A
  • Inrush Current (Typ.): Varies by input voltage
  • Leakage Current: <0.5mA

Protection Features:

  • Short Circuit: Hiccup mode, automatic recovery after fault condition removal
  • Over Load: ≤120%, Hiccup mode, automatic recovery after fault condition removal
  • Over Temperature: Shell surface temp 100°C±10°C, automatic recovery after temperature drop

Environmental Conditions:

  • Operating Temperature: -40~+60°C
  • Operating Humidity: 20 - 90%RH non-condensing
  • Storage Temperature and Humidity: -40 - +80°C, 10 - 95% RH non-condensing
  • Temperature Coefficient: ±0.03%/°C (0 - 50°C)
  • Vibration: 10〜500Hz, 2G 10min./1 cycle, period for 60min. each along X, Y, Z axes

Safety & EMC Standards:

  • Safety Standards: EN61347-1, EN61347-2-13 (EU), UL8750 (US)
  • Withstand Voltage: Varies by region
  • Isolation Resistance: I/P-O/P:100MΩ / 500VDC

Additional Information:

  • Net Weight: 0.25Kg
  • Dimensions: 171.55420mm (LWH)
  • Packing: 250190135mm, 20PCS/CTN, 5.1KG/CTN
  • Note: All parameters, unless specified, are measured at rated load and 25°C ambient temperature. Tolerance includes setup and load regulation.
