GLASS FACADES, CURTAIN WALLS
Transparent LED Glass Display
Transparent LED Glass Display is an architectural display solution that integrates LED technology directly inside the glass panel itself, transforming ordinary glazing into a seamless digital communication surface.
LED Built Into the Glass
Transparent LED Glass integrates LED technology directly inside the glass panel itself, manufactured as part of the glass structure without additional frameworks, visible modules or secondary display systems.
Natural Light and Open Sightlines
With transparency of up to 92% depending on the model, natural light passes through while vibrant digital content is displayed.
Permanent Architectural Integration
The glass and display become one structure, creating a cleaner architectural appearance, improved durability and a fully integrated facade solution.
Custom Glass Sizes
Laminated glass panels are available from 1000 × 2000mm up to 1000 × 3000mm, in FG 4, FG 6 and FG 8 pixel pitch models, with project-specific engineering available.
Intro
Overview
Key Features
- Embedded LED technology within glass panels
- Architectural glass and digital display in one system
- No external screens or visible display structures
- Maintains natural light and open sightlines
- Custom glass sizes available
Transparent LED Glass Display is an architectural display solution that integrates LED technology directly inside the glass panel itself, transforming ordinary glazing into a seamless digital communication surface.
Unlike LED films, mesh displays or externally mounted screens, Transparent LED Glass is manufactured as part of the glass structure, creating a clean and elegant appearance without additional frameworks, visible modules or secondary display systems.
Designed for premium commercial and architectural projects, the system combines transparency, digital content and building aesthetics in a single solution. It is ideal for shopping centres, luxury retail stores, corporate headquarters, airports, museums, hotels and landmark developments where visual impact and architectural integrity are equally important.
The transparent glass structure allows natural light to pass through while displaying vibrant digital content, enabling architects and designers to incorporate digital media without compromising the original design intent of the building.
Available in multiple pixel pitches, glass sizes and custom configurations, Transparent LED Glass Display provides a sophisticated solution for projects seeking permanent integration between architecture and digital communication.
Why Choose Transparent LED Glass Display?
Unlike Transparent LED Film or LED Mesh Displays that are applied to existing glass surfaces, Transparent LED Glass integrates the display technology directly into the glazing itself.
This creates a cleaner architectural appearance, improved durability and a fully integrated facade solution where the glass and display become one structure.
For premium architectural projects, corporate headquarters, luxury retail environments and landmark developments, Transparent LED Glass provides the highest level of design integration while maintaining the transparency and elegance of modern glass architecture.
Applications
- 01Glass Facades
- 02Curtain Wall Systems
- 03Corporate Headquarters
- 04Shopping Centres
- 05Hotels
- 06Airports
- 07Museums
- 08Exhibition Spaces
- 09Luxury Retail Stores
Installation Options
Glass Facades
Curtain Wall Systems
Permanent Architectural Integration
Project-Specific Engineering Solutions
Product details
Specifications
- Product Type
- Transparent LED Glass Display
- Available Models
- FG 4 / FG 6 / FG 8
- Display Technology
- Embedded LED Glass Technology
- Pixel Pitch Options
- FG 4: 4.63 × 4.63 mmFG 6: 5.95 × 6.00 mmFG 8: 8.33 × 8.33 mm
- Transparency
- FG 4: Up to 83%FG 6: Up to 85%FG 8: Up to 92%
- Brightness
- FG 4: 2000–2500 nitsFG 6: 2500–3000 nitsFG 8: 3500–4000 nits
- Glass Panel Sizes
- 1000 × 2000 mm1000 × 2250 mm1000 × 2500 mm1000 × 2750 mm1000 × 3000 mm
- Display Size
- Customisable
- Glass Type
- Laminated Transparent LED Glass
- Viewing Angle
- 140° Horizontal / 140° Vertical
- Operating Environment
- Indoor & Semi-Outdoor Applications
- Maximum Power Consumption
- Depending on Glass Panel Size and Pixel Pitch
- Control System
- Compatible with Leading LED Control Systems
- Customisation Options
- Custom Glass SizesPixel Pitch OptionsBrightness ConfigurationsProject-Specific Engineering Solutions
