SHOPPING CENTRES, TRANSPORT HUBS
Double-Sided LED Display
Double-Sided LED Displays are designed to maximise visibility in environments where audiences approach from multiple directions.
Two Audiences, One Display
High-resolution LED screens on both sides communicate messages, promotions and branding to two viewing areas simultaneously, without requiring additional floor space.
Slim-Profile Design
The ultra-slim double-sided structure integrates into modern architectural environments while maintaining excellent visibility from both directions.
Suspended or Freestanding
Suspended from ceilings, integrated into retail environments or freestanding in public spaces, it suits high-traffic locations.
Commercial Performance
Available in P1.86, P2.0, P2.5 and P3.0 with brightness up to 800 to 1200 nits and a refresh rate of 3840Hz or higher.
Intro
Overview
Key Features
- Dual-sided LED display for maximum visibility
- Simultaneous content display on both sides
- Slim cabinet construction
- Suitable for suspended and freestanding installations
- Ideal for high-traffic public environments
Double-Sided LED Displays are designed to maximise visibility in environments where audiences approach from multiple directions. Featuring high-resolution LED screens on both sides, these displays enable businesses to communicate messages, promotions and branding content to two viewing areas simultaneously without requiring additional floor space.
Ideal for shopping centres, retail walkways, airports, transportation hubs and commercial environments, Double-Sided LED Displays provide a highly effective digital signage solution for maximising audience engagement and advertising exposure. The slim-profile design allows seamless integration into modern architectural environments while maintaining excellent visibility from both directions.
Available in a range of pixel pitches and display sizes, the system delivers vibrant image quality, high refresh rates and reliable commercial performance. Whether suspended from ceilings, integrated into retail environments or installed within public spaces, Double-Sided LED Displays provide a versatile solution for high-traffic locations.
Applications
- 01Shopping Centres
- 02Retail Stores
- 03Airports
- 04Transport Hubs
- 05Commercial Buildings
- 06Universities
- 07Museums
- 08Exhibition Centres
Installation Options
Suspended
Ceiling Mounted
Freestanding
Retail Integrated
Product details
Specifications
- Product Type
- Double-Sided LED Display
- Display Technology
- Direct View LED
- Available Pixel Pitch Options
- P1.86, P2.0, P2.5, P3.0
- LED Technology
- SMD LED
- Pixel Configuration
- 1R1G1B
- Cabinet Material
- Die-Cast Aluminium
- Cabinet Thickness
- Ultra-Slim Double-Sided Structure
- Service Access
- Front Service
- Brightness
- Up to 800–1,200 nits
- Viewing Angle (H/V)
- 160° / 160°
- Grey Scale
- 14–16 Bit Adjustable
- Refresh Rate
- ≥3840Hz
- Frame Frequency
- 50 / 60Hz
- Brightness Adjustment
- 0–100%
- Colour Temperature
- 3000K–9500K Adjustable
- Input Voltage
- 100–240V AC
- Maximum Power Consumption
- Up to 500W/m²
- Average Power Consumption
- 125W/m²
- IP Rating
- IP20
- Operating Temperature
- -10°C to +40°C
- Operating Humidity
- 10%–90% RH
- Certifications
- CE, RoHS, SAA
- Customisation
- Display dimensions, pixel pitch, suspension systems and content management solutions can be customised to suit project requirements.
