ARCHITECTURAL LED FEATURES
Creative LED Display
Creative LED Displays are custom-engineered digital display solutions designed for projects that require more than a conventional flat screen.
More Than a Flat Screen
Creative LED Displays can be configured into curved walls, cylindrical columns, suspended rings, wave formations, immersive tunnels and freeform architectural installations.
Bespoke Structural Integration
Each display is custom engineered with bespoke structural integration, giving architects and designers virtually unlimited design possibilities.
Immersive Digital Environments
Suspended rings, ribbon displays and immersive LED tunnels transform shopping centres, museums and corporate headquarters into engaging digital experiences.
Close Viewing and Large Scale
Pixel pitch options from P1.25 to P4.0 suit both close-viewing and large-scale installations, with brightness from 600 to 2000 nits.
Intro
Overview
Key Features
- Custom architectural LED display solutions
- Supports curved, cylindrical and freeform designs
- Suitable for immersive digital environments
- Fine pixel pitch options for close viewing
- Custom dimensions and shapes available
Creative LED Displays are custom-engineered digital display solutions designed for projects that require more than a conventional flat screen. Utilising advanced LED display technology and bespoke structural integration, these displays can be configured into curved walls, cylindrical columns, suspended rings, wave formations, immersive tunnels and freeform architectural installations.
Ideal for shopping centres, museums, corporate headquarters, airports, universities and premium retail environments, Creative LED Displays enable architects, designers and developers to transform spaces into engaging digital experiences while maintaining exceptional image quality and visual impact.
Available in a range of fine pixel pitches, Creative LED Displays can be tailored to suit both close-viewing and large-scale installations, offering virtually unlimited design possibilities for modern commercial environments.
Applications
- 01Shopping Centres
- 02Retail Stores
- 03Luxury Brand Boutiques
- 04Corporate Headquarters
- 05Museums
- 06Universities
- 07Airports
- 08Exhibition Centres
- 09Experience Centres
- 10Government Buildings
Installation Options
Wall Mounted
Suspended
Freestanding
Column Wrapped
Ceiling Mounted
Custom Architectural Integration
Product details
Specifications
- Product Type
- Creative LED Display
- Display Technology
- Direct View LED
- Pixel Pitch Options
- P1.25, P1.56, P1.86, P2.0, P2.5, P3.0, P4.0
- Brightness
- 600–2,000 nits (depending on pixel pitch and application requirements)
- Refresh Rate
- ≥3840Hz
- Contrast Ratio
- Up to 10,000:1
- Viewing Angle
- 160° Horizontal / 160° Vertical
- Available Configurations
- Curved LED Displays, Cylindrical LED Displays, Ring LED Displays, Wave LED Displays, Immersive LED Tunnels, Ribbon LED Displays, Freeform LED Displays, Architectural LED Features
- Cabinet Material
- Die-Cast Aluminium
- Maintenance Access
- Front Service
- Operating Environment
- Indoor Applications
- Power Supply
- AC100–240V, 50/60Hz
- Input Signal Compatibility
- HDMI, DisplayPort, DVI, Network Control
- Certifications
- CE, RoHS, EMC, SAA
