HEADQUARTERS, BOARDROOMS, LOBBIES
Corporate LED Display
Corporate LED Displays are engineered for organisations seeking exceptional visual performance in professional environments.
SMD or COB
Fine Pitch SMD offers excellent performance for general corporate applications, while COB delivers superior contrast, enhanced durability and ultra-fine pixel pitches for premium environments.
Presentations With Detail
Presentations, dashboards, video conferencing and digital branding content are displayed with exceptional detail and consistency.
Seamless Architectural Integration
Front-service maintenance and slim die-cast aluminium cabinets allow seamless integration into modern architectural spaces while simplifying long-term servicing.
From Boardroom to Feature Wall
From compact boardroom displays to large-scale corporate feature walls, every system can be customised to suit project requirements.
Intro
Overview
Key Features
- Fine Pitch SMD and Flip-Chip COB options
- Pixel pitch from P0.94 to P2.5
- Up to 7680Hz refresh rate (COB)
- Front-service maintenance
- Slim die-cast aluminium cabinets
Corporate LED Displays are engineered for organisations seeking exceptional visual performance in professional environments. Designed for corporate headquarters, executive boardrooms, reception areas, control centres and premium experience spaces, these displays deliver seamless imagery, outstanding clarity and long-term operational reliability.
Available in both Fine Pitch SMD and advanced Flip-Chip COB technologies, Corporate LED Displays provide the flexibility to match different viewing distances, project requirements and budgets. Fine Pitch SMD options offer excellent performance for general corporate applications, while COB technology delivers superior contrast, enhanced durability and ultra-fine pixel pitches for mission-critical and premium environments.
With high refresh rates, wide viewing angles and accurate colour reproduction, Corporate LED Displays ensure presentations, dashboards, video conferencing and digital branding content are displayed with exceptional detail and consistency. Front-service maintenance and slim die-cast aluminium cabinets allow seamless integration into modern architectural spaces while simplifying long-term servicing.
Whether installed in a corporate lobby, executive briefing centre, university, government facility, museum or control room, Corporate LED Displays create an engaging visual platform that enhances communication, strengthens brand presence and supports data-driven decision making.
From compact boardroom displays to large-scale corporate feature walls, every system can be customised to suit project requirements, architectural considerations and operational objectives.
Applications
- 01Corporate Headquarters
- 02Reception Areas
- 03Corporate Lobbies
- 04Executive Boardrooms
- 05Meeting Rooms
- 06Control Rooms
- 07Universities
- 08Government Buildings
- 09Hospitals
- 10Museums
- 11Automotive Showrooms
- 12Brand Experience Centres
- 13Training Facilities
- 14Commercial Offices
- 15Premium Home Theatre Installations
Installation Options
Wall Mounted
Recessed
Front Fixed
Freestanding
Custom Architectural Integration
Product details
Specifications
- Product Type
- Corporate LED Display
- Available Pixel Pitch Options
- SMD P1.25, P1.53, P1.86, P2.0, P2.5 | COB P0.94, P1.25, P1.56
- LED Technology
- Fine Pitch SMD LED / Flip-Chip COB LED
- Pixel Configuration
- 1R1G1B
- Cabinet Dimensions
- 640 × 480 × 40.6 mm (SMD) | 600 × 337.5 × 27.5 mm (COB)
- Cabinet Material
- Die-Cast Aluminium
- Cabinet Weight
- Approx. 4.5–5.7 kg
- Service Access
- Front Service Maintenance
- Brightness
- SMD up to 600 nits | COB up to 800 nits
- Viewing Angle
- 160° Horizontal / 160° Vertical
- Contrast Ratio
- Up to 10,000:1
- Colour Gamut
- Up to NTSC 110%
- Grey Scale
- 14–16 Bit Adjustable
- Refresh Rate
- SMD ≥3840Hz | COB up to 7680Hz
- Frame Frequency
- 50Hz / 60Hz
- Brightness Adjustment
- 0–100% (Manual, Automatic or Scheduled)
- Colour Temperature
- 3000K–9500K Adjustable
- Input Voltage
- AC100–240V, 50/60Hz
- Maximum Power Consumption
- SMD ≤360W/m² | COB ≤475W/m²
- Average Power Consumption
- SMD ≤90W/m² | COB 125–250W/m²
- IP Rating
- SMD IP20 | COB Front Surface IP54
- Operating Temperature
- -10°C to +40°C
- Storage Temperature
- -40°C to +60°C
- Operating Humidity
- 10%–90% RH
- Storage Humidity
- 10%–90% RH
- LED Lifetime
- >100,000 Hours
- Customisation
- Display dimensions, cabinet configurations, mounting structures, processing systems and control platforms can be customised to suit project requirements.
- Certifications
- CE, RoHS, SAA
